| Part Number | 35363-1260 |
|---|---|
| Manufacturer / Brand | Affinity Medical Technologies - a Molex company |
| Category | Connectors, Interconnects > Rectangular Connectors - Headers, Male Pins |
| Description | CONN HEADER 12POS 2MM R/A TIN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Voltage Rating | - |
| Termination | Kinked Pin, Solder |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall |
| Series | Sherlock 35363 |
| Row Spacing - Mating | - |
| Pitch - Mating | 0.079" (2.00mm) |
| Packaging | Bulk |
| Overall Contact Length | - |
| Other Names | 0353631260 35363-1260-P 353631260 WM18941 |
| Operating Temperature | - |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 12 |
| Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyamide (PA), Nylon |
| Insulation Height | 0.217" (5.51mm) |
| Insulation Color | Natural |
| Ingress Protection | - |
| Features | - |
| Fastening Type | Locking Ramp |
| Detailed Description | Connector Header Through Hole, Right Angle 12 position 0.079" (2.00mm) |
| Current Rating | - |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Brass |
| Contact Length - Post | 0.126" (3.20mm) |
| Contact Length - Mating | 0.145" (3.70mm) |
| Contact Finish Thickness - Post | 78.7µin (2.00µm) |
| Contact Finish Thickness - Mating | 78.7µin (2.00µm) |
| Contact Finish - Post | Tin |
| Contact Finish - Mating | Tin |
| Connector Type | Header |
| Applications | Automotive, General Purpose |
